46
15.3 Toshiba ASD
• The interface acts as a TOSVERT-300MVi master simply by virtue of being
installed into a drive.
•
No configuration other than that indicated in section 4 is necessary, as the
interface automatically adapts to the ASD’s configured characteristics.
•
35 ASD items are accessible. These items are referenced by ASD
parameters SCAN_WR01_AS..SCAN_WR25_AS and
SCAN_RCV01_AS..SCAN_RCV10_AS. For the purposes of point
database numerical configuration, these ASD parameters have been
assigned the “parameter numbers” indicated in Table 4. For example, if
ASD parameter SCAN_WR05_AS is assigned “VDC_F_DSP”, then
accessing a point in the interface’s point database whose “Source Port” is
set to “ASD” and whose “Toshiba ASD Parameter” value is 15 will return
the drive’s DC voltage (in %). For further information on the
SCAN_xxxx_AS parameters and their settings, please refer to the relevant
ASD configuration manual and section 4 in this manual.
