36
• Timeout En: Checking this box will allow the point to participate in timeout
processing when a port network timeout event is detected.
• Timeout Value: This determines the value this point will default to upon the
occurrence of a network timeout. If a “Source Port” has been designated
(see below), then this value will also propagate to the configured remote
device connected to the designated port.
• Source Port: This determines the interface port that this point will obtain its
value from and write values to.
• Toshiba ASD:
o Parameter: The Toshiba ASD parameter (in decimal, 1 - 35) that
this point refers to.
• Modbus Master:
o Source ID: The ID (station address) of the Modbus slave that this
point refers to.
o Register: The holding register or input register within that slave
that this point refers to. The default register type is “holding
register”, but an “input register” will be accessed if the register
value entered here is 30001..39999.
• Modbus Slave:
o Register: The holding register number assigned to this point.
• Ethernet/IP: Note that these entry fields are only necessary for support of
the custom Electronic Data Sheet (EDS) download function, which will be
supported on a future firmware release. They will then allow explicit
messaging access to points as CIP parameter objects.
o Help: User defined help text, up to 24 chars.
o Units: User defined engineering units text, up to 5 chars.
o Data
Type: The data type of this point.
o Maximum: The max value of this point.
o Minimum: The min value of this point.
o Default: The default value of this point.
o Multiplier: The multiplier of this point.
o Divider: The divider of this point.
o Offset: The offset of this point.
o Precision: The precision, in decimal places, of this point.
o Scaling: Checking this box tells this point to use (value x
multiplier)/divider + offset to determine its actual value.
o Read only: Defines this point as read only when checked.
