QLight™ DP series
QLight DP series manual
page 31
TQ-445DP TQ-425DP TQ-115DP
Dimensions 588mm x 409mm x 363mm
(23.1” x 16.1” x 14.3”) 836mm x 511mm x 632mm
(32.9” x 20.1” x 24.9”) 559mm x 450mm x 600mm
(22” x 17.7” x 23.6”)
Net weight 34.5kgs (75.9lbs) 57kg (125.4lbs) 32.2kg (70.8lbs)
Components 1 x 12/1” LF/HF driver
1 x 6.5” MF driver 2 x 15” (381mm) LF drivers 1 x 15” (381mm) LF driver
Frequency
response 55Hz – 20kHz ±4dB 45Hz – 200Hz ±4dB 47Hz – 180Hz ±4dB
Dispersion 60 °H x 40°V @-6dB points N/A N/A
Max SPL 131dB cont., 137dB peak 132dB cont., 138dB peak 126dB cont., 132dB peak
Construction 15mm (1/2”) birch plywood 18mm (3/4”) birch plywood 18mm (3/4”) birch plywood
Grille Reticulated foam on expanded
steel mesh Reticulated foam on expanded
steel mesh Reticulated foam on expanded
steel mesh
Connectors (1) XLR female, (1) XLR male
wired pin 2 hot (1) XLR female, (1) XLR male
wired pin 2 hot (1) XLR female, (1) XLR male
wired pin 2 hot
Mains Neutrik PowerCon® Neutrik PowerCon® Neutrik PowerCon®
Options TurboBlue™ semi-matt textured
paint
TurboBlue™ semi-matt textured
paint TurboBlue™ semi-matt textured
paint
Due to continuing product improvement the above specifications are subject to change.
