APPENDIX B: TECHNICAL SPECIFICATIONS
TQ-308DP TQ-310DP TQ-315DP
Dimensions 464mm x 270mm x 301mm
(18.3” x 10.6” x 11.8”) 525mm x 315mm x 300mm
(20.7” x 12.4” x 11.8”) 691mm x 443mm x 420mm
(27.2” x 17.4” x 16.5”)
Net weight 15.5kg (34.1lbs) 20.5kg (45.1lbs) 32kgs (70.4lbs)
Components 1 x 8” (203mm) LF driver
1 x 1” (25mm) HF
compression driver 1 x 10” (254mm) LF driver
1 x 1” (25mm) HF compression
driver 1 x 15” LF driver
1 x 1.4” HF driver
Frequency
response 68Hz – 20kHz ±4dB 65Hz – 20kHz ±4dB 50Hz – 20kHz ±4dB
Nominal
dispersion 100 °H x 60°V @-6dB points 100 °H x 60°V @-6dB points 80 °H x 50°V @-6dB points
Max SPL 120dB cont., 126dB peak 124dB cont., 130dB peak 130dB cont., 136dB peak
Construction 12mm (1/2”) birch plywood 12mm (1/2”) birch plywood 18mm (3/4”) birch plywood
Grille Reticulated foam on
expanded steel mesh Reticulated foam on expanded
steel mesh Reticulated foam on expanded
steel mesh
Connectors (1) XLR female, (1) XLR male
wired pin 2 hot (1) XLR female, (1) XLR male
wired pin 2 hot (1) XLR female, (1) XLR male
wired pin 2 hot
Mains Neutrik PowerCon® Neutrik PowerCon® Neutrik PowerCon®
Options TurboBlue™ semi-matt
textured paint
TurboBlue™ semi-matt textured
paint TurboBlue™ semi-matt textured
paint
Due to continuing product improvement the above specifications are subject to change.
