E658130
- 31 -
Error code
Decimal
No.
Hexadecimal
No.
Description
Trip display
50 32H Analog input break detection fault e-18
51 33H CPU communications error e-19
52 34H Over torque boost fault e-20
53 35H CPU fault 2 e-21
55 37H Optional unit fault 2 e-23
58 3AH CPU fault 3 e-26
62 3EH Main module overload ol3
64 40H PTC fault e-32
65 41H Over-torque trip 2 ot2
69 45H Servo lock fault e-37
71 47H Auto-tuning error (PM motor) e-39
72 48H Over-torque / Overcurrent fault otc3
73 49H Small-torque / Small -current fault utc3
84 54H Auto-tuning error etn1
85 55H Auto-tuning error etn2
86 56H Auto-tuning error etn3
Fault record display example
(instruction code H74)
For read data: 011BH b15 b8 b7 b0
Fault record 2 Fault record 1
(01H: oc1) (1BH: err8)
(instruction code H74)
For read data：021CH b15 b8 b7 b0
Fault record 4 Fault record 3
(02H: oc2) (1CH: err9)
0 0 0 0 0 0 0 1 0 0 0 1 1 0 1 1
0 0 0 0 0 0 1 0 0 0 0 1 1 1 0 0
