Appendix C. Cable Distance
Cable Catagory Speed Max-Lobe Length* Max-RI\RO Length*
UTP 3 16Mbps 100 meters 150 meters
UTP 5 16Mbps 300 meters 300 meters
STP 5 16Mbps 400 meters 400 meters
UTP 3 4Mbps 300 meters 300 meters
UTP 5 4Mbps 500 meters 500 meters
STP 5 4Mbps 500 meters 500 meters
*Distances as tested with IBM Token Ring and SMC Token Elite Cards. Other cards guaranteed to
100 meters per 802.5 specification.
