Operations Manual
SV-2000-X2 Server (CENTRIX / JHSV)
Part Number: 1008080 Page 58 of 82
Version 1.4. 01/12/2010
Figure 6-23 DIMM Module Bank
1. Note the location of the alignment notch.
2. Align the notches on the new module with the
notches on the memory and press it firmly into
the bank.
NOTE: The tabs on the sides of the memory
module should secure the DIMM
automatically. When the DIMM locks into
place, you will hear a click.
6.14 Replacing the CMOS Battery
This section lists the procedures for replacing
the motherboard CMOS Battery.
1. Boot up the Server and enter set-up mode.
2. Record all the settings from the various BIOS
menus.
3. Power off the Server.
4. Remove the lid from the Server.
5. Locate the CMOS battery on the motherboard
(ref. Figure , Notation “H”).
6. Remove the old battery.
7. Replace it with the new battery.
8. Replace the lid and power on the Server.
9. Enter the set-up mode of the Server.
10. Re-enter any applicable settings through the
various BIOS menus.
