Software Update:
Digital television is a new medium. Apart from improved sound and image quality, it also pro-
vides the facility for interactive services. These new services are continually being developed
and improved by programme providers. In order to use these services it may occasionally be
necessary to update the software of the receiver.
Supply voltage:
LNBs are provided with electrical current via the coaxial cable. In order to achieve this, the
receiver supplies a voltage of 14 or 18 Volt
Transponder:
This has the task of processing one or more programmes on board the satellite. It receives
data from the ground station, amplifies them, and broadcasts them back to earth
Universal LNB:
Term used to describe a three-band LNB, capable of receiving the ranges FFS (10,70 - 11,70
GHz), BBS (11,70 - 12,50 GHz) and FFS High Band (12,50 - 12,75 GHz). The complete
range is generally divided into two bands:
Low Band: 10,70 - 11,80 GHz; LOF 9750 MHz
High Band 11,70 - 12,75 GHz ; LOF 10600 MHz
Viaccess
Digital encryption standard
9 Technical Data
DBS-Tuner:
Input frequency range 950 .... 2150 MHz
Input level range - 60 dBm ... - 25 dBm
DBS-Tuner Input F - Buchse
Input impedance 75 Ohm
AFC capture range +/- 3 MHz
Demodulation Shaped QPSK
Symbo lrate 15 ... 30 Mbaud/s, MCPC
FEC Viterbi and Reed-Solomon
Viterbi rates 1/2, 2/3, 3/4, 5/6, 7/8, automatic adjustment
Roll-off Factor 35 %
Demultiplexing: in accordance with ISO 13818-1
Video decoding:
Video compression MPEG-2 and MPEG-1 compatible
Up to MP@ML (main profile @ main level)
Video standard PAL / 25 Hz
Active image area 720 Pixel x 576 lines
Image formatt 4 : 3 / 16 : 9
Image material 16:9 Automatic adjustment for 16:9 TV sets (via SCART)
Letterbox Filterung for 4:3 TV sets
Audio decoding:
Audio compression MPEG-1 & MPEG-2 Layer I and II
Audio Mode Dual (main/sub), Stereo
Sampling frequencies 32 kHz, 44.1 kHz, 48 kHz,
33
