OPERATORS MANUAL
- 3-2 -
3.2.1 Main
This section describes the main items of the SETUP program. The SCU screen
can be divided into four areas:
• On the top line of the screen is the menu bar, which lists the titles of the
available menus. Each menu title contains a pull-down menu, which
displays items for setting.
• The left column of the screen displays the current configuration
information of the system. If an item in the pull-down menu is selected
which contains multiple choices, the left column displays the submenu
where you can make your selections.
• The right column of the screen gives help information of the selected
item.
• The bottom lines of the screen give keyboard instructions for moving
around and making selections.
3.2.2 Moving Around and Making Selections
A brief description of keyboard usage is listed next:
Key Function
Key Function
←, → Selects a menu title.
↑, ↓ Selects an item or option.
Enter Opens or closes the options window when an item is selected.
Space bar, Cycles through the pre-defined value for the selected item. Pressing the space bar brings
up the next value; pressing the minus (–) key does the contrary.
Esc 1) Exits the SCU program.
2) Returns to the previous menu if in a submenu.
3) Closes the options window if one is open.
Table 3-1 Keyboard Usage
NOTE : You are advised to use the touchpad or mouse (if installed), as it is more
straightforward than using the keyboard.
