TAG 1000 User Manual
Page 38
MIL-BOOK™
OPERATORS
MANUAL
- 2-8 -
Figure 2-9 Removing IEEE 1394 Port
2.3.9 EMI Accessory Descriptions
The user can use the following EMI Accessories for better EMI protection.
1. EMI Core
There are one same EMI cores. One is used to directly wrap around
the 1394 cable of the user near the 1394 port side.
NOTE
The cores should be put close to the computer side for best performance.
2. EMI Cable
There are two same EMI cables. One is for the microphone port and
the other is for the speaker port. The male connectors are connected to the
microphone and speaker ports, and the female connectors are connected to the
microphone and speaker(s).
3. Modem Cable
One modem cable together with the EMI core is used for the
modem port.
NOTE
The connector close to the EMI core should be connected to the
modem port of the computer for best performance.
