Page 91
89
MODEL
PART NAME
PART NO.
TYPE
MAKER
TGF-13F
GNF-107DC
30283D0700
NORMAL
SHINHAN
TGF-9F
7. EVAPORATER DEFROST HEATER
MODEL
PART NAME
PART No.
Spec.
MAKER
TGF-23F SHEATHED HEATER
30228L0802
445W
SANGDO
SPECIFICATION OF MAIN COMPONENTS
8. BALLAST
MODEL
PART NAME
PART NO.
QTY
WATT
CURRENT
TYPE
ADVANCE
MAGNETEK
TGF-23F
R-2P17-TP
703-L-TC-P
30285R1200
1
17W
0.21A
Rapid
RC-2S102-TP
949-LH-TC-P
30285R1300
1
110W
1.7A
Rapid
TGF-13F
R-1P32-TP
M-132R120C
30200A0120
1
32W
0.32A
Rapid
TGF-9F
R-1P825-TP
727-L-TC-P
30200A0131
1
25W
0.3A
Rapid
9. FLUORESCENT LAMP
MODEL
PART NAME
PART No.
NUMBER WATT LENGTH
DESCRIPTION
BULB MAKER
TGF-23F
F17T8/TL950
30236H0500
1
17W
12"
TL950, 5000K
T8
PHILIPS or GE
F48T12/CW/VHO 30236R1000
1
110W
48"
CW, 4100K
T12 PHILIPS or GE
TGF-13F
F32T8/TL950
30200D2800
1
32W
48"
TL80, 5000K
T8
PHILIPS
TGF-9F
F25T8/SP41
30236A0500
1
25W
36"
TL80, 5000K
T8
GE
10. ROCKER SWITCH
MODEL
TYPE
PART NO.
RATING
MAKER
TGF-23F
POWER SWITCH (RED)
30281R0200
125V/20A
SIGNAL LUX
LAMP SWITCH (GREEN)
30281R0100
125V/20A
SIGNAL LUX
TGF-13F
LAMP SWITCH
30281A0600
125V, 6A
DAESUNG
TGF-9F
11. TRANSFORMER & MAIN PCB
MODEL
TYPE
PART NO.
RATING
NOTE
TGF-23F
TRANSFORMER
30284L0100
115V/60Hz
DWS-115U
MAIN PCB
30243R0100
115V/60Hz
1FG1151
6. TEMPERATURE CONTROL
