4. SPECIFICATION OF MAIN COMPONENTS
1. COMPRESSOR
MODEL PART NAME PART NO.
HORSE
CAPACITY
TYPE OF
INPUT MAKER
POWER MOTOR
TGF-23F CAJ2432Z 30200R1000 1/2 HP
3,200 BTU/h
CSR 810W
TECUMSEH
(807 Kcal/h) (FRANCE)
TGF-13F AEZ2415Z 30200N4400 1/3 HP
1,459 BTU/h
CSIR 280W
TECUMSEH
(368 Kcal/h) (FRANCE)
TGF-9F HBL27YE-1 3952127G10 1/3 HP
896 BTU/h
CSR 220W DAEWOO
(226 Kcal/h)
2. COMPRESSOR RELAY, OVERLOAD
MODEL RELAY PART NO. OVERLOAD PART No. MAKER NOTE
TGF-23F 3ARR3*5R* - CST00AGF-(+) - TECUMSEH(FRANCE) Comp. Assembly
TGF-13F 3ARR12KP(+)479 - MRP24AIK - TECUMSEH(FRANCE) Comp. Assembly
TGF-9F PTC 068 3017906900 4TM-783SHB 3817910600 DAEWOO TEXAS INSTRUNENT
3. COMPRESSOR CAPACITOR
MODEL STARTING PART No. RUNNING PART No. MAKER Note
TGF-23F 160V 315µF - 400V 30µF - TECUMSEH(FRANCE) Comp. Assembly
TGF-13F 160V 250µF - - - TECUMSEH(FRANCE) Comp. Assembly
TGF-9F 220V 100µF 401RD35050 230V 10µF 400EL15130 DAEWOO DAEWOO
4. CONDENSER FAN MOTOR
MODEL PART NAME PART NO. POLE INPUT TYPE
BLADE
MAKER
(NUMBER)
TGF-23F IS-4420DWSG-1 3963320410 4P 47W
Shaded Pole AL
SUNGSHIN
Induction (5)
TGF-13F
IS-3225DWSK-1 3963326010 2P 36W
Shaded Pole Zytel
SUNGSHIN
TGF-9F Induction (6)
5. EVAPORATER FAN MOTOR
MODEL PART NAME PART NO. POLE INPUT TYPE
BLADE
MAKER
(NUMBER)
TGF-23F IS-4420DWSN-2A 3963328120 4P 47W
Shaded Pole AL
SUNGSHIN
Induction (5)
