70
1. Unscrew the screws securing the Thermostat
Plate and two screws securing the Duct.
2. Separate the Duct.
(Caution: Pulling the Duct to the front can
cause the Fan Blade to be bent.)
REPLACEMENT OF MAIN COMPONENTS
3. Unscrew four securing the Evaporator Fan
Motor Bracket.
4. Separate the Connectors of Fan Motor, the Nut
and replace the Fan Blade.
3. EVAPORATOR FAN MOTOR & BLADE(TGM-14R)
