14
4. SPECIFICATION OF MAIN COMPONENTS
1. COMPRESSOR
MODEL PART NAME PART NO.
HORSE
CAPACITY
TYPE OF
INPUT MAKER
POWER MOTOR
TGM69R AKA4482YXA 30200K2900 3/4 HP 8,200 BTU/h CSIR 1,190W TECUMSEH
TGM48R
TGM45R AKA4476YXA 30200A4700 1/2 HP
7,880 BTU/h
CSIR 750W TECUMSEH
TGM35R
(856 Kcal/h)
TGM33R AEA4448YXA 30200J2100 1/3 HP 4,650 BTU/h CSIR 457W TECUMSEH
TGM22R
TGM14R HBL27YE-1 3952127G10 1/3 HP
2,080 BTU/h
CSR 220W DAEWOO
TGM11R
(226 Kcal/h)
TGM5R HFL11Y-1 3953111E10 1/10 HP 874 BTU/h (95Kcal/h) RSIR 107W DAEWOO
2. COMPRESSOR RELAY, OVERLOAD
MODEL PART NAME PART NO. MAKER OVERLOAD PART NO. MAKER
TGM69R 820ARR2B19 - TECUMSEH 8300MRAK30 - TECUMSEH
TGM48R
TGM45R 82498-1 - TECUMSEH 8300MRAM53 - TECUMSEH
TGM35R
TGM33R 820RR12E72 TECUMSEH 8300MRTM75 TECUMSEH
TGM22R PTC 068 3017906900 DAEWOO 4TM-783RHB 3817908600 TEXAS INSTRUMENT
TGM14R
PTC 068 3017906900 DAEWOO 4TM-783SHB 3817910600 TEXAS INSTRUMENT
TGM11R
TGM5R PTC 068 3017906900 DAEWOO 4TM-293THB 3817906500 TEXAS INSTRUMENT
3. COMPRESSOR CAPACITOR
MODEL PART NAME PART NO. MAKER RUNNING PART NO. MAKER
TGM69R - - - - - -
TGM48R
125V
TGM45R - TECUMSEH - - TECUMSEH
TGM35R
378~445MFD
TGM22R 220V 100 401RD35050 DAEWOO 230V 10 400EL15130 DAEWOO
TGM14R 220V 100 401RD35050 DAEWOO 230V 10 400EL15130 DAEWOO
TGM11R 220V 100 401RD35050 DAEWOO 230V 10 400EL15130 DAEWOO
