Page 83: Model : tgf-23f
81
1. FEATURE CHART
SIGN PANEL
FLOURSECENT LAMP
DOOR ASSEMBLY
POWER SWITCH
LAMP SWITCH
< FRONT >
EVAPORATOR FAN
MOTOR BLADE
EVAPORATOR
FAN MOTOR
EVAPORATOR COIL
BACK GUARD
(AIR BAFFLE BACK)
CASTER
COMPRESSOR
CONDENSER FAN MOTOR
CONDENSER COIL
CASTER(WITH BRAKE)
BOTTOM GRILLE
DOOR HANDLE
SHELF
• Model : TGF-23F
• Model : TGF-23F
< SIDE >
