2-1
2. SPECIFICATIONS EM1-33039E
2. SPECIFICATIONS
2.1 PRINTER
2.1 PRINTER
Supply voltage Universal (automatic switching)
85-138 V, 50/60 Hz
187-276 V, 50/60 Hz
Be sure to use a power cord which meets the standard.
Power consumption 3.5 A, 260 W maximum (standby: 360 mA, 20 W maximum)
Operating temperature 5˚C ~ 40˚C
range
Relative humidity
25% ~ 85%RH (no condensation)
Print head Thermal print head 12 dots per mm (305 dots per inch)
Printing methods Thermal direct or Thermal transfer
Print speeds 76.2 mm/sec. (3 inch/sec.), 101.6 mm/sec. (4 inch/sec.),
203.2 mm/sec. (8 inch/sec.) When the media width is 160mm or less.
Maximum print width 213.3 mm (8.40 inches)
Dispensing modes Batch (Continuous), Strip (On-demand) and Cut modes
(Both cut and strip modes are available only when their respective modules
are fitted.)
Message display 20 characters x 1 line
Dimensions 437 mm (width) x 282 mm (depth) x 395 mm (height)
Weight 25 kg (without media and ribbon)
Available bar-code types JAN8, JAN13, EAN8, EAN8 + 2 digits, EAN8 + 5 digits
EAN13, EAN13 + 2digits, EAN13 + 5 digits
UPC-E, UPC-E + 2 digits, UPC-E + 5 digits
UPC-A, UPC-A + 2 digits, UPC-A + 5 digits
MSI, ITF, NW-7, CODE39, CODE93, CODE128
EAN128, Industrial 2 to 5
Two-dimensional code Data Matrix, PDF417,
Fonts Times Roman (6 sizes), Helvetica (6 sizes), Presentation (1 size),
Letter Gothic (1 size), Prestige Elite (2 sizes), Courier (2 sizes),
OCR (2 types), Writable characters (40 types), Outline font (1 type)
Rotations 0˚, 90˚, 180˚, 270˚
Standard interfaces Serial interface (RS-232C)
Parallel interface (Centronics)
Expansion I/O interface
Flash memory card interface
Optional interface High speed PC interface
B-872-QQ
Item
Model
∗
Data Matrix TM is a trademark of International Data Matrix, Inc.
PDF417 is a trademark of Symbol Technologies, Inc.
