Tripp Lite EMS1250UL User Manual
Page 3
Outlet details
2 Hospital-Grade GFCI duplex outlets
INPUT
Nominal Input
Voltage(s) Supported
120V AC
Recommended
Electrical Service
DC INPUT: Requires 12VDC input source capable of delivering 127A for the required duration (when used at full
continuous capacity - DC requirements increase during Over-Power and Double-Boost operation). For automotive
applications, professional hardwire
Maximum input
amps / watts
DC INPUT: Full continuous load - 127A at 12VDC. AC INPUT: 32 amps at 120VAC with full inverter and charger load
(11 A max charger-only / combined input load to support charger and AC output is automatically controllable to
66%-33%-0% based on AC output lo
Input connection
type
DC INPUT: 175A Anderson DC connector. AC INPUT: NEMA 5-15P hospital-grade input plug
Voltage
compatibility (VAC)
120
Voltage
compatibility (VDC)
12
BATTERY
Expandable battery
runtime
Runtime is expandable with any number of user supplied wet or gel type batteries
DC system voltage
(VDC)
12
Battery recharge rate
14A/55A (selectable)
LEDS ALARMS & SWITCHES
Switches
3 position on/off/remote switch enables simple on/off power control plus "auto/remote" setting that enables distant
on/off control of the inverter system when used in conjunction with included External switch for wired remote control
of APS unit
Front panel LEDs
Set of 6 LEDs offer continuous status information on load percentage (6 levels reported) and battery charge level (7
levels reported). See manual for sequences.
SURGE / NOISE SUPPRESSION
AC suppression
joule rating
760
PHYSICAL
Shipping
Dimensions (HWD/in)
12.5 x 11 x 10.75
Shipping
Dimensions
(HWD/cm)
21.75 x 27.94 x 27.31
Shipping weight (lbs)
24.8
Shipping weight (kg)
11.2
Unit Dimensions
(HWD/in)
7 x 8.75 x 9
Unit Dimensions
(HWD/cm)
17.78 x 22.23 x 22.86
Unit weight (lbs)
23.2
Unit weight (kg)
10.5
Cooling method
Multi-speed fan
