Side Rotary Common Section 6 - 15
60” SIDE ROTARY MOWER
ITEM
PART NO.
QTY.
DESCRIPTION
1
34975
1
HEAVY DUTY GRASSKAT COMBO
06320005
1
STD DUTY GRASSKAT COMBO
06320008
1
HEAVY DUTY GRASSKAT CABLE
2
34980
1
SPINDLE ASSY,TM 60"
3
06504016
1
CURRENT MOTOR,(M365-1 1/4" 14-SPLINE)
34981
1
ORIGINAL MOTOR,(M365-1 1/4" 14-SPLINE)
4
06410254
2
SKID,OUTBOARD,TM60
5
22992
*156
CHAIN,10 LINK
6
6T2270
14
PLOW BOLT,3/8" X 1" NC
7
22016
*26
FLATWASHER,3/8"
8
21625
*30
HEX NUT,3/8",NC
10
6T1025
4
CAPSCREW, 1/2 x 2,GR 8,NC
10A
06533006
4
FLATWASHER,1/2,SAE,GR 8
11
21990
*8
LOCKWASHER, 1/2"
12
34972
*4
PLATE,CAP,CHAIN
13
21631
*16
CAPSCREW, 3/8 x 1-1/4,NC
14
34974
*2
ROD,CHAIN,INNER,TM60
15
34973
*2
ROD,CHAIN,OUTER,TM60
16 - 20 SEE NEW ROTARY KNIVES AND DISKS PAGE
21
21988
*16
LOCKWASHER, 3/8"
22
6T2290
6
CAPSCREW, 5/8x 1-3/4 (NOT SHOWN)
23
21575
*25
HEX NUT, 5/16”,NC
24
21580
*25
CAPSCREW, 5/16” x 1” NC
25
21987
*25
LOCKWASHER, 5/16”
26
22015
*25
FLATWASHER, 5/16”
27
06520084
*2
ROTARY SIDE FLAP
28
06370029
1
TIRE GUARD, LEFT
29
06370030
*1
TIRE GUARD, RIGHT
30
21731
*4
CAPSCREW, 1/2” x 1-1/2” NC
31
21732
*4
CAPSCREW, 1/2” x 1-3/4” NC
32
21725
*8
HEX NUT, 1/2”,NC
33
22018
*8
FLATWASHER, 1/2”,WIDE
34
06520085
*1
ROTARY CENTER FLAP
35
06400207
*3
ROTARY FLAP STRAP
36
06410207
*1
FLAP MOUNT, RIGHT
37
06410206
*1
FLAP MOUNT, LEFT
38
06410208
*1
FLAP MOUNT, CENTER
CABLE LIFT HEAD ONLY
39
21745
1
NYLOCK NUT, 1/2
40
21727
1
SPRING, PUSHOFF, SIDE RTRY
41
27005
1
CAPSCREW, 1/2 x 7,NC
42
22018
1
FLATWASHER,1/2",WIDE
OPTIONAL SQUARE FLAP
43
06410946
1
MNT,FLAP,LH,EXT,TSR
44
06410947
1
MNT,FLAP,RH,EXT,TSR
45
06410948
1
COVER,FLAP,EXT,TSR
46
06401184
2
STRAP,FLAP,EXT,TSR
47
06520331
2
FLAP,EXT,TSR
48
21580
6
CAPSCREW,5/16 X 1 NC
49
22015
12
FLATWASHER,5/16
50
21575
6
HEX NUT, 5/16,NC
51
21632
10
CAPSCREW,3/8" X 1-1/2" NC
52
22016
20
FLATWASHER,3/8",GR8
53
21625
10
HEX NUT,3/8",NC
8/26/05
* QUANTITY VARIES - REAR CHAIN GUARD & REAR FLAP GUARD IS OPTIONAL.
STANDARD UNIT COMES WITH FRONT CHAINS AND LEFT TIRE GUARD
