Side Rotary Common Section 6 - 2
TABLE OF CONTENTS
SECTION ASSEMBLY PAGE
CABLE LIFT ASSEMBLY 6-4
COMBO DRAFT BEAM 6-6
60” SIDE CABLE ROTARY MOWER ASSEMBLY 6-8
72” SIDE CABLE ROTARY MOWER ASSEMBLY 6-10
60” SIDE COMBO RTRY MOWER ASSEMBLY 6-12
60” SIDE ROTARY MOWER 6-14
60” SPINDLE AND SPACER 6-16
72” SIDE COMBO ROTARY MOWER ASSY 6-18
TM72” MOTOR ASSEMBLY 6-20
CHAIN GUARDS 6-22
SIDE ROTARY CASTER WHEEL ASSEMBLY 6-24
RESERVOIR TANK FILTER ASSEMBLY 6-26
MOWER SPINDLE ASSEMBLIES 6-28
HYDRAULIC LIFT CYLINDER 6-32
ROTARY KNIVES AND DISKS 6-34
CASTER WHEEL ASSEMBLY 6-35
ROTARY MOTORS 6-36
FRONT HYDRAULIC PUMP 6-38
TSR MOTOR 6-38
COOLER ASSEMBLY 6-40
2 SPOOL HUSCO VALVES 6-42
SOLENOID VALVE ASSEMBLY 6-54
SOLENOID BRAKE VALVE ASSEMBLY 6-55
BRAKE VALVE ASSEMBLY W/METRI PAK 6-56
SOLENOID BRAKE VALVE SCHEMATIC 6-57
TRAVEL LOCK LIFT BEAM 6-58
SIDE MOWER TRAVEL LOCK (COMBO) 6-59
SWITCHBOX SCHEMATIC 6-60
