Side Rotary Common Section 6 - 5
CABLE LIFT ASSEMBLY
ITEM PART NO. QTY. DESCRIPTION
1 6T0103A 1 DRAFT BEAM (STD 25 LB, 45 3/8”)
6T0103E OPT. DRAFT BEAM (EXTENDED 6” 4WD)
6T0103L OPT. DRAFT BEAM (EXTENDED 15”)
6T0105 OPT. DRAFT BEAM (STD WITH TRAVEL LOCK)
6T0108 OPT. DRAFT BEAM (30 LB CHANNEL, 45 3/8”)
2 6T0150 1 CYLINDER 3” X 18”
3 6T0151R 1 CYLINDER 3” X 10”
4 6T0100 1 LOWER SHEAVE BRACKET
5 6T0101 1 UPPER SHEAVE BRACKET
6 33768 2 SHEAVE
7 6T0110 1 LIFT CABLE (STD 1/2” X 87 1/2”)
6T0110E OPT. LIFT CABLE (EXTENDED 6” 4WD)
6T0110L OPT. LIFT CABLE (EXTENDED 15”)
8 6T0115 1 TURN BUCKLE
9 6T0112 1 SHACKLE WITH PIN
10 6T2999 1 OUTER DRAFT BEAM PIN 1 1/2” X 14 1/2”
11 6T3001 1 INNER DRAFT BEAM PIN 1 1/2” X 15 3/4”
12 6T3005 1 PIN ,1” W/ CAP
13 TB1033 2 CLEVIS PIN 1” X 4”
14 6T3004 1 R - CLIP 3/16”
15 6T3010 1 UPPER SHEAVE PIN WITH ZERK 3/4” X 3”
16 6T3009 1 LOWER SHEAVE PIN WITH ZERK 3/4” X 2 1/2”
17 6T3020 2 R - CLIP 5/32”
18 6T2272 1 SET SCREW 3/8” X 1/2”
19 6T3211 1 GREASE ZERK 1/8” STRAIGHT
20 21836 1 CAPSCREW 3/4” X 3”
21 21688 2 CAPSCREW 7/16” X 3 1/4”
22 21825 2 HEX NUT 3/4”
23 21677 2 NYLOCK NUT 7/16”
24 22023 1 FLAT WASHER 1”
25 6T0104N 2 SHEAVE PIN BUSHING 1” OD X 3/4” ID
26 21833 1 CAPSCREW 3/4” X 2 1/4”
27 22021 1 FLAT WASHER 3/4”
28 21993 1 LOCK WASHER 3/4”
29 06537021 4 ROLL PIN
30 6T0106 1 TRAVEL LOCK BRACKET
31 6T4258 1 BREATHER 1/2”
32 34396 2 RESTRICTOR
33 34244 2 ELBOW FITTING 1/2”
34 * REF. MAIN FRAME REFER TO TRACTOR PARTS SECTION
3-22-02
