3 external interface – Toshiba PROFIBUS-DP PBDP-110 User Manual
Page 8
7
1.3 External Interface
Note that for clarity the above diagram shows the PBDP-110 unit removed from its
case. However, it is not necessary to remove the unit from its case in order to
install or configure the PBDP-110.
Data_Exchange
LED
SHIELD grounding terminal
(refer to Section 4).
Profibus
network
connector
Drive “A” connector
Drive “B” Connector
Address selection
DIP switches
MMI port
