9.2 Input (Status) Data Format
The size of the input data structure from the PBDP-110 to the network master
depends on the module selected from the GSD file for the network configuration tool.
Module #1, intended for applications where only 1 drive is connected to the PBDP-
110 (via Channel A), is comprised of 24 bytes structured as six 32-bit words. Module
#2, intended for applications where drives are connected to both Channel A and
Channel B, is comprised of 48 bytes structured as twelve 32-bit words.
Offset Data
Offset Data
0 Reserved
24 Reserved
1 Reserved
25 Reserved
2
Drive A status high byte
26
Drive B status high byte
3
Drive A status low byte
27
Drive B status low byte
4 Reserved
28 Reserved
5 Reserved
29 Reserved
6
Drive A output frequency
high byte
30
Drive B output frequency
high byte
7
Drive A output frequency
low byte
31
Drive B output frequency
low byte
8 Reserved
32 Reserved
9 Reserved
33 Reserved
10
Drive A output current high
byte
34
Drive B output current high
byte
11
Drive A output current low
byte
35
Drive B output current low
byte
12 Reserved
36 Reserved
13 Reserved
37 Reserved
14
Drive A output voltage high
byte
38
Drive B output voltage high
byte
15
Drive A output voltage low
byte
39
Drive B output voltage low
byte
16
Reserved /
Drive A response bits
40
Reserved /
Drive B response bits
17 Reserved
41 Reserved
18
Drive A parameter number
response high byte
42
Drive B parameter number
response high byte
19
Drive A parameter number
response low byte
43
Drive B parameter number
response low byte
20 Reserved
44 Reserved
21 Reserved
45 Reserved
22
Drive A parameter data
response high byte
46
Drive B parameter data
response high byte
23
Drive A parameter data
response low byte
47
Drive B parameter data
response low byte
