19
(continued…)
SW1 SW2 SW3 SW4 SW5 SW6 SW7 Addr SW1 SW2 SW3 SW4 SW5 SW6 SW7 Addr
OFF OFF OFF OFF OFF OFF ON 64 OFF OFF OFF OFF OFF ON ON 96
ON OFF OFF OFF OFF OFF ON 65 ON OFF OFF OFF OFF ON ON 97
OFF ON OFF OFF OFF OFF ON 66 OFF ON OFF OFF OFF ON ON 98
ON ON OFF OFF OFF OFF ON 67 ON ON OFF OFF OFF ON ON 99
OFF OFF ON OFF OFF OFF ON 68 OFF OFF ON OFF OFF ON ON 100
ON OFF ON OFF OFF OFF ON 69 ON OFF ON OFF OFF ON ON 101
OFF ON ON OFF OFF OFF ON 70 OFF ON ON OFF OFF ON ON 102
ON ON ON OFF OFF OFF ON 71 ON ON ON OFF OFF ON ON 103
OFF OFF OFF ON OFF OFF ON 72 OFF OFF OFF ON OFF ON ON 104
ON OFF OFF ON OFF OFF ON 73 ON OFF OFF ON OFF ON ON 105
OFF ON OFF ON OFF OFF ON 74 OFF ON OFF ON OFF ON ON 106
ON ON OFF ON OFF OFF ON 75 ON ON OFF ON OFF ON ON 107
OFF OFF ON ON OFF OFF ON 76 OFF OFF ON ON OFF ON ON 108
ON OFF ON ON OFF OFF ON 77 ON OFF ON ON OFF ON ON 109
OFF ON ON ON OFF OFF ON 78 OFF ON ON ON OFF ON ON 110
ON ON ON ON OFF OFF ON 79 ON ON ON ON OFF ON ON 111
OFF OFF OFF OFF ON OFF ON 80 OFF OFF OFF OFF ON ON ON 112
ON OFF OFF OFF ON OFF ON 81 ON OFF OFF OFF ON ON ON 113
OFF ON OFF OFF ON OFF ON 82 OFF ON OFF OFF ON ON ON 114
ON ON OFF OFF ON OFF ON 83 ON ON OFF OFF ON ON ON 115
OFF OFF ON OFF ON OFF ON 84 OFF OFF ON OFF ON ON ON 116
ON OFF ON OFF ON OFF ON 85 ON OFF ON OFF ON ON ON 117
OFF ON ON OFF ON OFF ON 86 OFF ON ON OFF ON ON ON 118
ON ON ON OFF ON OFF ON 87 ON ON ON OFF ON ON ON 119
OFF OFF OFF ON ON OFF ON 88 OFF OFF OFF ON ON ON ON 120
ON OFF OFF ON ON OFF ON 89 ON OFF OFF ON ON ON ON 121
OFF ON OFF ON ON OFF ON 90 OFF ON OFF ON ON ON ON 122
ON ON OFF ON ON OFF ON 91 ON ON OFF ON ON ON ON 123
OFF OFF ON ON ON OFF ON 92 OFF OFF ON ON ON ON ON 124
ON OFF ON ON ON OFF ON 93 ON OFF ON ON ON ON ON 125
OFF ON ON ON ON OFF ON 94 OFF ON ON ON ON ON ON 126
ON ON ON ON ON OFF ON 95
Note that the “ON” position of each switch is the “down” position and that the “OFF”
position is the “up” position. Refer to the indicator markings on the switch.
The address switch settings are read by the interface only on power-up. Therefore, if
the address is changed, be sure to power the PBDP-110 off momentarily by cycling
power to the drive connected to “Channel A” or by disconnecting/reconnecting the
cable connecting “Channel A” to the drive.
