PERFORMANCE

66D

Frequency response

(1)

49Hz-51kHZ

Max SPL

(2)

117dB

Distortion

<0.4%

Dispersion @-6dB, 10kHz, horizontal

90 degrees

DRIVE UNITS

Drive Units – LF/MID

2 x 165mm (6

1

/

2

”) multi fibre

paper pulp cone

WideBand

TM

HF

25mm (1”) titanium dome,

neodymium magnet system.

ELECTRONIC SYSTEM

Inputs

600 balanced XLR/Jack,

SPDIF RCA

SPDIF sampling rate

44.1 – 96kHz

Input Sensitivity (0dBu = 0.775mV)

-10dBu to +4dBu

for a max SPL of 117dB

Amplifier output power

100W LF / 50W HF

Outputs

SPDIF slave out RCA

User Controls

Front panel mounted

on/standby/mute switch,

multi-function LED,

Rear panel mounted trim +6/-12dB,

80Hz high pass switch for AV use,
16-way Activ-Assist

TM

switch array

Reveal 66D

Active centre channel reference
monitor with Active-Assist™
Optimised bass-reflex loaded
cabinet with 40mm thick front
baffle
Two shielded 165mm (6

1

/

2

”)

woofers, multi fibre paper
pulp cones
Shielded 25mm (1”) titanium
dome neodymium tweeter
WideBand

TM

HF extended to

51kHz corrects phase response
Active bi-amplification
(100W LF / 50W HF)

Putting together an active surround
system? Look no further than the
Reveal 66D as the ideal centre
channel monitor.

With its extended WideBand™
response, the R66D preserves the
harmonic structure of recorded music
and vocals; this results in a more
natural and accurate reproduction
of the original source. Ready to
integrate with your analogue or digital
production environment the R66D
includes Tannoy’s Activ-Assist™
equalisation technology.
