Features:
40mm thick contoured baffle
Driver lossy-coupled to cabinet
10 screw driver chassis fixing
Flux control rings on LF drivers
Applications:
Home studios/composition
Project studios, users of PC/MAC
DAW’s
Professional recording, broadcast,
post production studios & editing suites
PERFORMANCE 5A
Frequency response (1) 70Hz-30kHZ
Max SPL (2) 109dB
Distortion <0.7%
Dispersion @-6dB, 10kHz, horizontal 90 degrees
DRIVE UNITS
Drive Units – LF/MID 130mm (5”) multi fibre
paper pulp cone
WideBand TM HF 25mm (1”) soft dome,
neodymium magnet system.
ELECTRONIC SYSTEM
Inputs 600 balanced XLR/ 1 / 4 ”
jack combination
Sensitivity 775mV for 40W
Amplifier output power 40W LF / 20W HF
User controls Front panel mounted
on/standby/mute switch, multi-function LED,
gain control
Cabinet dimensions 298.8 x 271.5 x 184mm
(HxWxD exc. heatsink) 11 3 / 4 x 10 3 / 4 x 7 1 / 4 ”
Reveal 5A
Active compact reference monitor
Ultra high bandwidth response out to 30kHz
Optimised bass-reflex loaded cabinet with 40mm thick front baffle
Shielded 130mm (5”) woofer, multi fibre paper pulp cone
Shielded 25mm (1”) soft dome neodymium tweeter
Whether you’re building a studio on a budget, or you just need an active monitor
with a small footprint, the Reveal 5A is your choice. Built to the same high standard
as the rest of the Reveal line, the R5A packs performance, accuracy and value
into a compact enclosure that’s ready to share the desktop with the rest of
your gear. Priced right for the beginner, the R5A delivers WideBand™
performance that will impress even the most seasoned pro.
