TS12
500W RMS
26Hz(-6dB)
15Hz
2 x line level phone
2 x XLR balanced
2 x XLR balanced
(direct or 80Hz high pass)
2nd order low pass,
50Hz - 150Hz, -6dB
After approximately 12 mins.
in absence of input signal
300mm (12“)
Closed box
22 litre / 0.78cu.ft
Phase control
Crossover defeat switch for
LFE operation
Soft limiting to avoid overload
LF extension control
372 x 335 x 335mm
14
5 /
8
x 13 1 /
8
x 13 1 /
8
”
12.5kg / 27.5 lbs
120V nominal AC~60Hz
230V nominal AC~50Hz
120V - T5AL / 250V
230V - T2.5AL / 250V
600VA
Features
Rigid cabinet, down-firing driver
BASH® digital power amplifier
Stereo line level inputs
XLR input and output
Direct or switched 80Hz high pass
Auto power on and sleep function
Soft-clip limiting
Gain and phase controls
