Page 28
28
TASCAM DA-45HR
5 - RC-D45 remote control unit (option)
The optional RC-D45 remote control unit is plugged
into the
REMOTE IN [37]
jack at the rear of the tape
deck.
Most of the controls on the remote control unit dupli-
cate the controls on the main tape deck. The explana-
tion of the controls is given below:
[43] OPEN/CLOSE
Equivalent to
[2]
on the main unit.
[44] CAPS
Used to toggle between uppercase and lowercase
when entering titles (see 4.8.1, "Entering and editing
titles").
[45] CHECK
Equivalent to the shifted
CHAR [22]
on the main
unit.
[46] POSITION
Equivalent to the shifted
SKIP PLAY [25]
on the
main unit.
[47] ID SELECT
Equivalent to the shifted
AUTO ID [26]
on the main
unit.
[48] AUTO ID
Equivalent to the
AUTO ID [26]
on the main unit.
[49] INS/+ and DEL/-
Equivalent to the shifted
MARGIN RESET [23]
and
DISPLAY [24]
on the main unit.
[50] EDIT
Equivalent to the shifted
MENU [28]
on the main
unit.
[51] ENTER
Equivalent to the
ENTER [27]
on the main unit.
[52] MENU
Equivalent to the
MENU [28]
on the main unit.
[53] Numeric keys
These keys may be used for a variety of purposes.
When playing back a tape, entering a program num-
ber using these keys, and pressing
PLAY
will locate
the tape to that program and start playing. If
PAUSE
is pressed rather than
PLAY
, the tape will be located
to the start of the program and the deck will enter
pause mode.
When editing and entering titles, these keys may be
used as a convenient way of entering characters.
Repeated presses of a key will cycle through the
characters associated with the key. For instance, the
2
key, when pressed once, will enter
2
in the title.
Pressing it again will enter
d
(or
D
if the CAPS
mode is active), pressing it one more time will enter
e
and pressing it again will enter
f
. If it is pressed
one more time, it will enter
2
.
[54] Cursor keys
These keys are used to move the cursor left and right
when entering and editing program titles.
[55] COUNTER MODE
Equivalent to the
COUNTER MODE [21]
on the
main unit.
[56] MARGIN RESET
Equivalent to the
MARGIN RESET [23]
on the
main unit.
[57] CHAR
Equivalent to the
CHAR [22]
on the main unit.
[58] DISPLAY
Equivalent to the
DISPLAY [24]
on the main unit.
[59] SKIP PLAY
Equivalent to the
SKIP PLAY [25]
on the main unit.
[60] SINGLE PLAY
Equivalent to the
SINGLE PLAY [31]
on the main
unit.
[61] REPEAT
Equivalent to the shifted
COUNTER MODE [21]
on the main unit.
5.1 Remote control transport keys
[62] SKIP keys
Equivalent to the
SKIP
keys
[12]
on the main unit.
[63] MEMO 1 and MEMO 2 keys
Equivalent to the shifted
LOC 1 [29]
and
LOC 2
[30]
on the main unit.
[64] SAMPLING MONITOR key
Equivalent to pressing the
RECORD
key on the
main unit once (see 17, "RECORD key").
[65] REW and F FWD
Equivalent to the
REW
and
F FWD
keys
[13]
on the
main unit.
