10
Specifications
Model: APSX700HF
AC Input Connection: IEC 60320 C14
AC Output Connection: IEC 60320 C13
Battery Connection: Hardwire
Inverter
Continuous Output Capacity (@ 20° C) 700W/700VA
Peak Output Capacity (Instantaneous) 1400W
DC Input Volts (Nominal) 12 V DC
DC Input Voltage Range 10-15 V DC
Minimum DC Fuse Rating 125 A
DC Input Current @ Nominal V DC Full Load: 72 A
Battery Charger
Input: 230 V, 50 Hz AC
Charging Capacity DC: 6 A
Line VAC Operation
Total Input AC Current (Continuous, Charger at Maximum): 4.5 A
Maximum Output Current (Continuous): 3 A
Note on Labeling
Two symbols are used on the APS labels.
V~: AC Voltage : DC Voltage
Battery Wiring
For maximum efficiency, keep battery wires as short as possible. For very short runs, 6 AWG
(4.115 mm) wiring may be adequate; for longer runs, 4 AWG (5.189 mm) or 2 AWG (6.544 mm)
wiring is recommended.
Note: Acceptable power is directly dependent on wire length, i.e. the shorter the wiring, the better the
performance. Total wiring length is the sum of the positive and negative wiring lengths.
