SPECIFICATIONS
43
SPECIFICATIONS
Tuner & Channel Decoder
Input/Loop through Connector F-type, IEC 169-24, Female
Frequency Range 950 ~ 2150MHz
Signal Level Input -65 ~ -25dBm
LNB Power & Polarization
Vertical : +13.5VDC
Horizontal : +18VDC
Current : Max. 500mA with Overload Protection
22KHz Tone
Frequency : 22±1KHz
Amplitude : 0.65±0.2V
DiSEqC Control Version 1.0/1.1/1.2/1.3 Compatible
Demodulation QPSK
Input Symbol Rate 1~45 Msps
Code Rate 1/2, 2/3, 3/4, 5/6 and 7/8
MPEG Transport Stream A/V Decoding
Transport Stream ISO/IEC 13818-1 MPEG-2 Transport stream Specification
Profile Level MPEG-2 MP@ML
Aspect Ratio 4:3, 16:9, Pan & scan, Letterbox
Video Resolution 720 x 576
Audio Decoding MPEG-1 Layer 1 & 2
Main System
Main Processor Power PC
A/V & Data In/Out
RCA A/V
Video CVBS output
Audio L/R output
SCART
Video CVBS/S-VIDEO/RGB/YUV output
Audio L/R output
RS-232C
9 pin D-sub type
Transfer rate : max. 115.2Kbps
RF-Modulator
RF-Connector 75 :, IEC 169-2, Female/Male
Frequency 470 ~ 860MHz(PAL) / 470 ~ 890MHz(NTSC)
Output Service CH21 ~ 69(PAL) / CH3,4,14 ~ 83(NTSC)
TV standard PAL G/I/K/NTSC-M selectable by Menu
