MENU OPERATIONS

29

A. Motorized DiSEqC1.3

Select Enable or Disable. If you are using DiSEqC1.3 switch, set to Enable.

B. Satellite Name

Select a satellite that will be used to identify a motor system.

C. Satellite Angle

It is the longitude of the selected satellite and it can be set automatically in case of

selecting a satellite name. You can use numeric keys of RCU to enter the angle. East or

West will be selected by

,

button.

D. My Longitude

It means the longitude of your location. You can select the angle, East and West by

,

or numeric button.

E. My Latitude

It means the latitude of your location. You can select the angle, South or North by

,

or numeric button.

F. Reference Position

Go to Reference position (Ø°)

G. Move : After searching the position you want by Goto the position item, you can

tune the antenna to go to the exact position by this item.

,

button moves the

antenna to anti-clockwise and clockwise respectively.

H. Frequency : Selects the Transponder to catch the strong signal.

I. Goto the position

After setting the Longitude, Latitude and the longitude of the selected satellite, this

menu is used when you want to move the desired direction (position) of the dish saved

before. Its moving limit is ±65°.
