Figure 4-13 Network Configuration Screen
Table 4-7 NETWORK CONFIGURATION MENU Options
Parameter
Description/Action
Alarm
This item allows you to enable (Report) or disable (Mask) the DL3800E unit
from reporting alarms or sending SNMP traps from any of the individual E1
network ports.
To change the present Alarm mode, use the UP and DOWN ARROW keys
to highlight the Alarm item in the appropriate line for the desired port, and
use the Space Bar to toggle between Report and Mask. Highlight Confirm,
and press the Enter key to confirm any change. (Default - Mask)
Active/Restore Mode
Selects the Active/Restore Mode for each of the E1 network ports.
To change the present mode, use the UP and DOWN ARROW keys to
highlight the Active/Restore Mode option for the desired port, and use the
Space Bar to toggle between the following selections until the desired choice
appears: use w/auto restore (failed line is restored automatically when
problem is solved); use w/manual restore (user must manually restore line);
Never Use (never mux data onto this line); Install/Test only (always mux
data onto this line, even when it’s bad). (Default - Never Use)
CRC4
Allows CRC4 coding to be enabled or disabled
Major 01/01/90 04:58:17 Unit: 0 NET : 2 (114)
Network 15 Minute UAS Major Threshold Exceeded
Major 01/01/90 04:58:17 Unit: 0 NET : 1 (114)
Network 15 Minute UAS Major Threshold Exceeded
DIGITAL LINK DL3800E SR 2.00.00 NODE 7: 01/01/90 05:55:07 MJ
SELECTED DEVICE ADDRESS: 7.00.000 NAME:
NETWORK CONFIGURATION Exit Confirm
PORT
ALARM
ACTIVE/RESTORE CRC4
TSLOT16
N1
N2
N3
N4
N5
1
REPORT
Use w/auto restoreENABLE
DATA
1
1
1
1
1
2
REPORT
Use w/auto restoreENABLE
DATA
1
1
1
1
1
3
MASK
Never Use
ENABLE
DATA
1
1
1
1
1
4
MASK
Never Use
ENABLE
DATA
1
1
1
1
1
5
MASK
Never Use
ENABLE
DATA
1
1
1
1
1
6
MASK
Never UseENABLE
DATA
1
1
1
1
1
7
REPORT
Use w/auto restoreENABLE
DATA
1
1
1
1
1
8
MASK
Never Use
ENABLE
DATA
1
1
1
1
1
Primary Clock Source: Xmt: Int Rcv: Net 1
Secondary Clock Source: Xmt: Net Rcv: Net 2
DSU MODE: Inverse Mux (Standard operation) Suppress Yellow Det.: Disabled
Second Error restoral interval: Immediate
Hardware Revision: Port 3&4: -- Port 5&6: -- Port 7&8: --
