Quantum Scalar 50 Tape Drive Installation Instructions
Document 81-81769-01 B01
September 2007
Cabling the Tape Drives 9
Figure 7 Scalar 50 Cable
Configuration (Native Fibre
Channel Half-Height Drives) Back of Library Ethernet
Power Fibre Channel
host/SAN Fibre Channel
host/SAN
Tape drives
1 and 2
Tape drives
3 and 4
