Quantum Scalar 50 Tape Drive Installation Instructions
Document 81-81769-01 B01
September 2007

10

Cabling the Tape Drives

Figure 8 Scalar 50 Cable
Configuration (Stacked)

Scalar 50 (master library)

Scalar 50 (slave library)

Scalar 50 (slave library)

Host computer

Tape
drive 1

Tape
drive 2

Tape
drive 2

Tape
drive 1

Tape
drive 1

Tape
drive 2

Host computer

Host computer

Ethernet

The library
host and
Ethernet
network are
connected only
to the Master
library.
