Quadra-Fire • QFP38 Series • 4061-300 Rev i • 9/09
72
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
Stocked
at Depot
ITEM
DESCRIPTION
COMMENTS
PART NUMBER
Log Set Assembly
1
Log 1 (Back Log)
4061-170
Log 2 (Ember Bed)
Not shown
4061-171
2
Log 3 (Front Right Log)
4061-172
3
Log 4 (Front Left Log)
4061-173
4
Log 5 (Right Log)
4061-174
5
Log 6 (Left Log)
4061-175
6
Log 7 (Right Middle Log)
4061-176
7
Log 8 (Left Middle Log)
4061-177
8
Log 9 (Decorative Left Log)
4061-178
9
Log 10 (Decorative Right Log)
4061-179
10
Refractory Retainer
4013-090
11
Refractory - Left Side
4061-150
12
Refractory - Lower Back
4051-148
13
Refractory - Right Side
4061-151
14
Refractory - Upper Back
4061-153
15
Intake Collar Assembly
4002-002
16
Heat Zone Cover Plate
Qty 2
4051-122
17
Glass Clip Assembly
Qty 4
33858
Y
18
Damper Bracket
4061-136
19
Burner Assembly
4061-015
Y
20
Hearth Pan
4061-123
21
Andiron
Qty 2
4051-311
22
Glass Frame Assembly
4061-012
Y
23
Glass/Gasket Assembly
4061-013
24
Glass Frame
4061-119
25
Glass Retainer
Qty 4
4051-124
26
Fan Assembly
4051-007
27
Junction Box
4061-023
Y
Flue Gasket
4000-225
Lava Rock Bag Assembly
4040-094
Lava Rock (2 lbs.)
4021-296
Mineral Wool
14333B
Vermiculite
28746
Installation Instructions & Owner's Manual
4061-300
Additional service part numbers appear on following page.
QFP38-NG, QFP38-LP
