Page 35: Two 45° elbows replacing one 90° elbow
Quadra-Fire • QFP38 Series • 4061-300 Rev i • 9/09
35
Figure 7.5
Two Elbows
1. Top Vent - Horizontal Termination - (continued)
Figure 7.4
Two 45° Elbows replacing One 90° Elbow
4 ft min.
(1.22 m)
20 ft max.
(6.10 m)
1 ft min.
(.30 m)
H
1
V
1
V
2
H
2
Installed
Vertically
V
1 min
H
1 max
V
2 min
H
2 max
feet
1
2
1
3
meters
0.30
0.61
0.30
0.91
feet
2
4
2
7
meters
0.61
1.22
0.61
2.13
feet
3
6
3
14
meters
0.91
1.83
0.91
4.27
