Page 16

Setting Up the Pump(s)

3-4

3.3.2 Stacking Two Pumps onto One Motor

Refer to Figures 3-5 through 3-7 and Figure B.

Figure 3-5. Placing the Second Pump

Figure 3-6. Aligning the Rotor Shaft

on Top of the First Pump

of the Second Pump

Figure 3-7. Securing Both Pumps to the Motor

LONG
MOUNTING
SCREWS

FACE OF
MOTOR

FLAT HEAD
SCREWDRIVER

FIRST PUMP

SECOND
PUMP

FACE OF
MOTOR

FIRST
PUMP

SECOND
PUMP
