Setting Up the Pump(s) 3
3-2
3.3 Attaching the Pump
3.3.1 Attaching a Single Pump Directly to the Motor
Refer to Figures 3-1 through 3-4 and Figure A.
Figure 3-1. Pump in Closed Position Figure 3-2. Aligning the Rotor Shaft
Figure 3-3. Aligning the Pins and Holes Figure 3-4. Securing the Pump to
the Motor
FACE OF
MOTOR
STANDARD
MOUNTING
SCREWS
FACE OF
MOTOR
TOP ALIGNMENT
PIN
BOTTOM
ALIGNMENT PIN
ROTOR SHAFT
FLAT HEAD
SCREWDRIVER
MOUNTING
HOLES
MOTOR
SHAFT
