3
Setting Up the Pump(s)
3-1
3.1 Introduction
To attach a single pump directly to a pump motor, follow the
procedure in Section 3.3.1.
To stack two pumps to a motor, follow the procedure in
Section 3.3.2.
To attach the pump to an adapter plate (for your own motor),
follow the procedure in Section 3.3.3.
To use your own adapter plate, follow the procedure in
Section 3.3.4.
Before you mount the pump to any pump motor, make
sure that power to the motor is turned off.
3.2 Required Hardware
Number of Pumps Mounting Screw Mounting Screw Number of Adapter Plate*
Stacked Type Part Number Mounting Screws Assembly Number
1 Standard FPU500-SMS** 2 FPU500-AP
2 Long FPU500-LMS
†
2 FPU500-AP
* Optional adapter plate assembly includes mounting screws and pins
** Supplied standard with pump; can only be used to mount a single
pump
†
Must be specified at the time of ordering the pump; can only be used
for mounting 2 stacked pumps
NOTE
