32
Connecting Your Components —Continued
• With connection , you can listen via speaker set B.
• To connect the recorder digitally, use connections and , or and .
The AV receiver has an AC outlet on its rear panel for
connecting the power cord of another AV component.
The other component’s power switch can then be left in
the ON position so that it turns on or off when the AV
receiver is set to On or Standby.
Caution:
• Make sure that the capacity of the component that
you connect to the AC OUTLET does not exceed
the stated capacity (e.g., 100 W).
Notes:
• Onkyo components connected via should be
connected directly to a wall outlet, not the AV
receiver’s AC OUTLET.
• The socket type and capacity depends on the
country in which you purchased the AV receiver.
Connecting a Cassette, CDR, MiniDisc, or DAT Recorder
Connection AV receiver Signal flow Cassette/CDR/MD/DAT recorder
TAPE IN L/R
TAPE OUT L/R
⇐
⇒
Analog audio L/R output
Analog audio L/R input
DIGITAL IN COAXIAL
⇐
Digital coaxial output
DIGITAL IN OPTICAL 3
⇐
Digital optical output
COA
XIAL
REMOTE CONTROL
OPTICAL
1
Y
PB
PR 2
3
DIGITAL IN
L
R
L
R
L
L
R
R
V
S
CD TAPE
ANTENNA
FM AM 75
COMPONENT
IN 3
IN IN OUT
OUT
IN IN OUT
IN IN IN OUT
IN 2 IN 1
VIDEO
VIDEO 2 VIDEO 1
VIDEO 2 VIDEO 1 DVD
DVD MONITOR
OUT
SURROUND BACK
SPEAKERS
SUB
WOOFER
FRONT SURROUND SURR BACK CENTER OUT
REC PLAY
IN OUT
L
R
L
R
IN
TAPE
L
R
OPTICAL
3
OPTICAL
OUT
DIGITAL IN
COAXIAL
COAXIAL
OUT
b
c
a
Step 1:
Choose a connection that matches the recorder (
, , or ), and then make the connection. a b c
Cassette recorder, CDR, etc.
Connect one or the
other
These connections
must be assigned
(see page 35)
a
a b a c
a
b
c
Connecting the Power Cord of Another Component
L
R
L
R
SURROUND
SPEAKERS
PRE OUT
SUB
WOOFER
FRONT SPEAKERS A
FRONT SPEAKERS B
AV RECEIVER
AC OUTLET
AC 120V SWITCHED 120W 1A MAX.
60Hz
CENTER SPEAKER
AC OUTLET
AC 120V
SWITCHED
120W 1A MAX.
60Hz
AC OUTLET
AC 230-240V
SWITCHED
100W MAX.
50Hz
European model American model
