SYSTEM PLANNING SYSTEM 4
System 4 is a four-way quad-amplified system. Amplifier 1 is bi-amplified for the front separates. Amplifier 2 is configured for two-way
operation. The front channels are configured for two 4-ohm midbass drivers. The rear channels are configured two 4 ohm subwoofers. The RGC-1
controls the subwoofer level from the dashboard of the vehicle.
Amplifier 1
Lowest recommended impedance is 2 ohms stereo operation
Front channels are configured for stereo operation
Front channels are configured for bandpass operation
Rear channels are configured for stereo operation
Rear channels are configured for high-pass operation
Amplifier 2
• Lowest recommended impedance in 2 ohms stereo
•
Front channels are configured for stereo operation
• Front channel input configured for bandpass operation
• Rear channels configured for summed stereo operation
•
RGC –1 connected to rear gain point controls bass level for the system
