3.2 The I/O Address Map
The OME-PCI-1002 registers are given below. The address of each register
is determined by adding the offset to the base address of the corresponding
section.
Section Offset Name Access Length
1 4ch
PCI interrupt control
register
R/W 8/16/32 bits
00h 8254 timer1 R/W 8/16/32 bits
04h 8254 timer2 R/W 8/16/32 bits
08h 8254 timer3 R/W 8/16/32 bits
0Ch 8254 control register W 8/16/32 bits
10h
Analog input channel
control register
W
8/16/32 bits
10h Status register R 8/16/32 bits
14h
Analog input gain
control register
W 8/16/32 bits
18h
General control
register W
8/16/32 bits
1Ch A/D software trigger W 8/16/32 bits
1Ch Clear Interrupt R 8/16/32 bits
20h Digital output register W 16/32 bits
20h Digital input register R 16/32 bits
2
30h A/D data register R 16/32 bits
