CON3: Analog input/output connector pin assignment. (For OME-PCI-1002H/L)
Pin Name Pin
Name
1
Analog input 0/0+
20
Analog input 16/0-
2
Analog input 1/1+
21
Analog input 17/1-
3
Analog input 2/2+
22
Analog input 18/2-
4
Analog input 3/3+
23
Analog input 19/3-
5
Analog input 4/4+
24
Analog input 20/4-
6
Analog input 5/5+
25
Analog input 21/5-
7
Analog input 6/6+
26
Analog input 22/6-
8
Analog input 7/7+
27
Analog input 23/7-
9
Analog input 8/8+
28
Analog input 24/8-
10
Analog input 9/9+
29
Analog input 25/9-
11 Analog
input
10/10+
30
Analog input 26/10-
12 Analog
input
11/11+
31
Analog input 27/11-
13 Analog
input
12/12+
32
Analog input 28/12-
14 Analog
input
13/13+
33
Analog input 29/13-
15 Analog
input
14/14+
34
Analog input 30/14-
16 Analog
input
15/15+
35
Analog input 31/15-
17 Analog
ground 36
N.C.
18 N.C. 37
Digital
ground
19 External
trigger
Notes:
1. When configured for differential inputs (JP1 3-5, 4-6), Pins 1-16 are the
positive inputs and Pins 20-35 are the negative inputs.
2. N.C. = No Connection
