Appendix
En-92
The following tables show how video signals at different resolutions are output by the AV receiver.
NTSC/PAL
✔: Output available
s
*1 Available resolutions: [640 × 480 60 Hz], [800 × 600 60 Hz], [1024 × 768 60 Hz], [1280 × 1024 60 Hz]
*2 Supported resolutions: [3840 × 2160 24/25/30 Hz], [4096 × 2160 24 Hz]
*3 When video signals of personal computers connected to PC IN are output from HDMI OUT SUB, they may not display properly on some TVs.
*4 Supported resolutions for HDMI OUT SUB.
Video Resolution Chart
HDMI Component Composite
4K *2 1080p/24 1080p 1080i 720p 480p/576p 480i/576i 1080p 1080i 720p 480p/576p 480i/576i 480i/576i
HDMI 1080p/24 ✔ ✔ *4
1080p ✔ ✔ ✔ *4
1080i ✔ ✔ ✔ ✔ *4 ✔
720p ✔ ✔ ✔ ✔ ✔ *4
480p/576p ✔ ✔ ✔ ✔ ✔ ✔ *4
480i/576i ✔ ✔ ✔ ✔ ✔ ✔ ✔ *4
Component 1080p ✔ ✔ ✔ *4 ✔
1080i ✔ ✔ ✔ ✔ *4 ✔ ✔
720p ✔ ✔ ✔ ✔ ✔ *4 ✔
480p/576p ✔ ✔ ✔ ✔ ✔ ✔ *4 ✔
480i/576i ✔ ✔ ✔ ✔ ✔ ✔ *4 ✔ ✔
Composite 480i/576i ✔ ✔ ✔ ✔ ✔ ✔ *4 ✔ ✔
PC IN (Analog RGB) *1*3 ✔ ✔ ✔ ✔ ✔ ✔
Output
Input
