22
EN
1A23
Connections
1 Use a standard antenna cable to connect the wall jack to the ANT IN jack on STB.
2 Use a standard audio cable to connect the audio output jacks (L, R) of STB to the audio input jacks (L, R) on
the TV.
3 Use an S-video cable to connect the S-VIDEO output jack on STB to an S-video input jack on the TV.
4 Set the resolution selection switch to “480i.”
5 After completing the connection to the TV, plug the AC power cord of the TV into the AC outlet, then turn
the TV on.
6 Set the TV to the input mode.
NOTE:
Refer to the TV owner’s manual for further information.
7 Plug the AC power cord of STB into the AC outlet, then turn STB on.
NOTE:
When using an S-video cable to connect, the resolution of the video signal output will always be 480i.
