www.RuggedCom.com 3 RuggedServer™ RS416
RuggedServer™ RS416
Modular 16-Port Serial Device Server with Integrated Managed Ethernet Switch
RS232/RS485/RS422 &
IRIG-B TTL
IED IED IED
IED IED IED
IED IED IED
RS232/RS485/RS422 &
IRIG-B TTL
RS232/RS485/RS422 &
IRIG-B TTL
IRIG-B TTL
IRIG-B TTL
IRIG-B TTL
GPS Time Source
024:07:00:00
Clock Source:
• GPS
• IEEE 1588 version 2
• IRIG-B
• NTP
• Local Clock
RSG2288 – Grand Master Clock
RSG2288 – Transparent Clock
RS416 – Slave / Ordinary Clock
NTP NTP
IRIG-B Serial
RS416 – Slave / Ordinary Clock
IEEE 1588
IRIG-B Serial
Typical Network Architecture: Distributing a Time Source over IRIG-B TTL
Typical Network Architecture: Distributing a Time Source over IEEE 1588 version 2
