www.RuggedCom.com 10 RuggedServer™ RS416
RuggedServer™ RS416
Modular 16-Port Serial Device Server with Integrated Managed Ethernet Switch
RS416 -______ -______ -____ -____ -____ -____ -____ -____ -____ -____ -____
Main Mount PS1 PS2 S1 S2 S3 S4 S5 S6 R
Slot 5
Slot 6
RS416
Slot 1
Slot 2
Slot 3
Slot 4
Main: Ethernet and Power Connectors
„ „ R = Ethernet on rear; LED panel on front; power connector on rear
„ „ F = Ethernet on front; LED panel on front; power connector on rear
„ „ B = Ethernet on rear; LED panel on top; power connector on rear
„ „ T = Ethernet on front; LED panel on top; power connector on rear
Mount: Mounting Options
„ „ RM = 19” Rack Mount Kit
„ „ DP = DIN and Panel Mount Kit
„ „ RD = 19” Rack, DIN, and Panel Mount Kit
„ „ 00 = No Mounting Option
PS1 and PS2: Power Supply 1 and 2
„ „ 24 = 24VDC (10-36VDC), screw terminal block
„ „ 48 = 48VDC (36-59VDC), screw terminal block
„ „ HI = 88-300VDC or 85-264VAC, screw terminal block
„ „ 24P = 24VDC (10-36VDC), pluggable terminal block
„ „ 48P = 48VDC (36-59VDC), pluggable terminal block
„ „ HIP = 88-300VDC or 85-264VAC, pluggable terminal block
„ „ XX = No Power Supply (PS2 Only)
S1, S2, S3, S4: Serial Port Modules for Slots 1, 2, 3, and 4 2
„ „ XX = Empty (S2,S3,S4 Only)
„ „ 3D = 4 x RS232/RS422/RS485 via DB9
„ „ 3R = 4 x RS232/RS422/RS485 via RJ45
„ „ FS = Fiber Serial Interface (ST Connector)
„ „ ID = 4 x RS232/RS422/RS485 & IRIG-B via DB9 1
„ „ IR = 4 x RS232/RS422/RS485 & IRIG-B via RJ45 1
S5, S6: Ethernet Modules for Slots 5 and 6 2
„ „ XXXX = Empty (S6 Only)
„ „ TX01 = 2 x 10/100Tx RJ45
„ „ FL01 = 2 x 10FL - Multimode, 850nm, ST
„ „ FX01 = 2 x 100FX - Multimode, 1300nm, ST
„ „ FX02 = 2 x 100FX - Multimode, 1300nm, SC
„ „ FX11 = 2 x 100FX – Multimode, 1300nm, LC
„ „ FX03 = 2 x 100FX - Multimode, 1300nm, MTRJ
„ „ FX04 = 2 x 100FX - Singlemode, 1300nm, ST, 20km
„ „ FX05 = 2 x 100FX - Singlemode, 1300nm, SC, 20km
„ „ FX06 = 2 x 100FX - Singlemode, 1300nm, LC, 20km
„ „ FX07 = 2 x 100FX - Singlemode, 1300nm, SC, 50km
„ „ FX08 = 2 x 100FX - Singlemode, 1300nm, LC, 50km
„ „ FX09 = 2 x 100FX - Singlemode, 1300nm, SC, 90km
„ „ FX10 = 2 x 100FX - Singlemode, 1300nm, LC, 90km
„ „ IRIG = 1 x IRIG-B in, BNC
1 x IRIG-B out, BNC (S5 only)
R: ROS ® firmware encryption
„ „ E = ROS ® encryption algorithms are restricted to a maximum
key-length of 56 bits, an export permit is not required
„ „ Blank = ROS ® encryption algorithms are not restricted to a
maximum key-length of 56 bits, an export permit is required
Notes: 1. When IR or ID are ordered the IRIG module must be ordered
for slot 5
2. IEEE 1588 Hardware Assist and Internal clock capable units are
only available on units sold with the IRIG module
Order Codes
Example Order Codes:
RS416-R-RM-24-XX-3D-3D-XX-XX-TX01-XXXX-E
19” Rack mounted, 24VDC power supply, 2 10/100 RJ45
Ethernet Ports, 8 DB9 Serial Ports, with all Ports on the
rear, encryption key-length of 56 bits
RS416-F-RM-48-48-3R-3R-3R-3R-FX01-FX01
19” Rack mounted, Dual 48VDC power supply, 4 100FX
(Multi Mode 1300nm Fiber) Ethernet ports, 16 RJ45 Serial
Ports, with all Ports on the front, encryption key-length not
restricted to 56 bits
RS416-F-RM-HI-XX-3R-3R-3D-3D-FX01-TX01-E
19” Rack mounted, HI power supply, 2 100FX (Multi Mode
1300nm Fiber) Ethernet Ports, 2 10/100 RJ45 Ethernet
Ports, 8 RJ45 Serial Ports, 8 DB9 Serial Ports, with all Ports
on the front, encryption key-length of 56 bits
Accessories/Options
82-01-0002 - Conformal Coating
41-11-0011 - Cable support brackets
43-10-0007 - Power cable (North America three
prong connector -> beau)
