Raypak Advanced Design Boilers are design certified by AGA/CGA for outdoor installation. Roof water drainage must be
diverted away from boilers installed under overhangs.
TABLE 2
OUTDOOR INSTALLATION MINIMUM CLEARANCES
Boiler Size
Boiler Side
500
750
1000
Rear
6"
6"
6"
Right
36” (Water side)
36" (Water side)
36" (Water side)
Left
36"
36"
36"
Top
0"
0"
0"
Vent
1"
1"
1"
WARNING:
Combustion air inlet (blower air inlet) should have 6" minimum clearance from any obstruction, i.e. walls or
other appliances.
