CAUTION
Caution to Be Taken for This Product:
• Before mounting this product, be sure to check the pin positions.
8. Precautions
9. Correspondence of Connectors J1, J2
Table 2 Correspondence of the connectors
IMPORTANT
Notes on This Product:
• We cannot accept any request for repair.
• For inquiries about the product or the contents of this manual, contact your local distributor.
Renesas Tools Homepage
http://www.renesas.com/en/tools
(NC: No connection)
J1-1
79
J1-26
53
J2-1
3
J2-26
29
J1-2
77
J1-27
54
J2-2
5
J2-27
30
J1-3
80
J1-28
55
J2-3
6
J2-28
31
J1-4
81
J1-29
56
J2-4
7
J2-29
32
J1-5
82
J1-30
57
J2-5
8
J2-30
33
J1-6
83
J1-31
58
J2-6
9
J2-31
34
J1-7
84
J1-32
59
J2-7
10
J2-32
35
J1-8
85
J1-33
60
J2-8
11
J2-33
36
J1-9
86
J1-34
61
J2-9
12
J2-34
37
J1-10
87
J1-35
62
J2-10
13
J2-35
38
J1-11
88
J1-36
63
J2-11
14
J2-36
39
J1-12
89
J1-37
64
J2-12
15
J2-37
40
J1-13
90
J1-38
65
J2-13
16
J2-38
91
J1-14
41
J1-39
66
J2-14
17
J2-39
92
J1-15
42
J1-40
67
J2-15
18
J2-40
93
J1-16
43
J1-41
68
J2-16
19
J2-41
94
J1-17
44
J1-42
69
J2-17
20
J2-42
95
J1-18
45
J1-43
70
J2-18
21
J2-43
96
J1-19
46
J1-44
71
J2-19
22
J2-44
97
J1-20
47
J1-45
72
J2-20
23
J2-45
98
J1-21
48
J1-46
73
J2-21
24
J2-46
99
J1-22
49
J1-47
74
J2-22
25
J2-47
100
J1-23
50
J1-48
75
J2-23
26
J2-48
1
J1-24
51
J1-49
76
J2-24
27
J2-49
4
J1-25
52
J1-50
78
J2-25
28
J2-50
2
Pin No. of
connector
Pin No. of
M3T-DIRECT100S
Pin No. of
connector
Pin No. of
M3T-DIRECT100S
Pin No. of
connector
Pin No. of
M3T-DIRECT100S
Pin No. of
connector
Pin No. of
M3T-DIRECT100S
