Reliable Data-Logger DL-04 - Manual (Page 7)

Reliable Scale Corporation
Model DL-04 DATA-LOGGER
User Manual Page 7 of 38 Rev. 1.70
4.1 Log Data
The chief function of the
DL-04 is the Log Data process.
The screen prompts the operator through the necessary steps, issuing
instructions as required. Once the operator initiates a job, each record is
saved automatically for future transfer and analysis.
Once logging has begun, the screen is updated every log interval with
the latest log information. This maintains a record of:
• Tool Depth with units
• Line Speed with units
• Entry Time
• Line Load with units
• Entry Number (max. 113,825)
1. From the Main Menu, select Log
Data.
MAIN MENU
1 Log Data
2 Resume Logging
Select # more:
T
Operator is prompted for required
information starting with Well Name Well Name:
„
F2 : Alpha
F4 : Quit ENTR: Accept
2. Key in the Well name.
Example: K14 If letters are used press
F2 to enter alpha mode
The screen will change slightly
Well Name:
„
F2 : Accept alpha
f: Next position
