Reliable Data-Logger DL-04 - Manual (Page 18)

Reliable Scale Corporation
Model DL-04 DATA-LOGGER
User Manual Page 18 of 38 Rev. 1.70
5. Configuration
Some operating features of the DL-04 can be modified to suit the
equipment being used. Other parameters such as the date and time need
to be set in order to make accurate logs. All parameters are set from the
Configuration Menu.
1. From the Main Menu, select
Configuration.
MAIN MENU
6 Pint Data
7 Configuration
Select # more: S
2. Screen shows first two items of the
Configuration Menu. Use the UP and
DOWN arrow keys to scroll through all
the options.
CONFIGURATION MENU
1 Set Date
2 Set Time
Select # more: S
CONFIGURATION MENU
3 Configure Ports
4 Set Depth Units
Select # more: S
3. To return to the Main Menu, select Exit
Configuration.
CONFIGURATION MENU
6 Set Password
7 Exit Configuration
Select # more: S
